Example: Random city

Published 2018-03-21 | Author: Pascal Seppecher

An isometric view of a random city.

Download as: [PDF] [TEX]  •  [Open in Overleaf]

Random city

Do you have a question regarding this example, TikZ or LaTeX in general? Just ask in the LaTeX Forum.
Oder frag auf Deutsch auf TeXwelt.de. En français: TeXnique.fr.

% Random city
% Author: Pascal Seppecher
\documentclass[tikz,border=10pt]{standalone}
\usetikzlibrary{backgrounds}
\usepackage{ifthen}
% The blue print color
\definecolor{blueprintcolor}{RGB}{20,20,100}

% The shadow color
\colorlet{shadow}{blueprintcolor!50!white}

% The light color
\colorlet{light}{white!90!blueprintcolor}

% The background color
\colorlet{background}{blueprintcolor}

% The basic size of a block
\newcommand\defaultside{0.6}

% The height of a storey
\newcommand\floorheight{0.08}

% The minimum number of stories
\newcommand\storeymin{20}

% The maximum number of stories
\newcommand\storeymax{40}

% The width of a window
\newcommand\window{0.05}

% The angles of x,y-axes
\newcommand\xaxis{210}
\newcommand\yaxis{-30}

% Facade style random list
\pgfmathdeclarerandomlist{facade}{{\hlines}{\vlines}{\grid}{\grid}{\grid}}

% Vertical thickness
\newcommand\vthickness{thin}

% Horizontal thickness
\newcommand\hthickness{thin}

% Selects at random the thickness of the horizontal lines
\newcommand\setvthickness{
  \pgfmathrandominteger{\alea}{0}{3}
  \ifthenelse{\alea=0}{\renewcommand\vthickness{thick}}{}
  \ifthenelse{\alea=1}{\renewcommand\vthickness{thin}}{}
  \ifthenelse{\alea=2}{\renewcommand\vthickness{very thin}}{}
  \ifthenelse{\alea=3}{\renewcommand\vthickness{ultra thin}}{}
}

% Selects at random the thickness of the vertical lines
\newcommand\seththickness{
  \pgfmathrandominteger{\alea}{0}{3}
  \ifthenelse{\alea=0}{\renewcommand\hthickness{thick}}{}
  \ifthenelse{\alea=1}{\renewcommand\hthickness{thin}}{}
  \ifthenelse{\alea=2}{\renewcommand\hthickness{very thin}}{}
  \ifthenelse{\alea=3}{\renewcommand\hthickness{ultra thin}}{}
}

% Draws vertical lines on each side of the block
\newcommand\vlines[2]{
  \pgfmathsetmacro\size{#1 * \floorheight}
  \pgfmathsetmacro\max{#2/\window}
  \foreach \col in {1,...,\max}
  {
    \pgfmathsetmacro\xx{-\col * \window}
    \draw[\vthickness,draw=shadow, shift={(\yaxis:\xx)}] (0,0)--(0,\size);
    \draw[\vthickness,draw=light, shift={(\xaxis:\xx)}] (0,0)--(0,\size);
  }
}

% Draws horizontal lines on each side of the block
\newcommand\hlines[2]{
  \foreach \floor in {0,...,#1}
  {
    \pgfmathsetmacro\z{\floor * \floorheight}
    \draw[\hthickness,draw=shadow, shift={(90:\z)}] (150:#2)--(0,0);
    \draw[\hthickness,draw=light, shift={(90:\z)}] (0,0) -- (30:#2);
  }
}

% Draws horizontal and vertical lines on each side of the block
\newcommand\grid[2]{
  \vlines{#1}{#2}
  \hlines{#1}  {#2}
}

% Draws a block at the specified position
\newcommand\block[2]{
  % Computes the height of the block
  \pgfmathsetmacro\height{#2 * \floorheight}

  % Erases the background
  \fill[fill=background]
    (0,0) -- (150:#1) -- ++(0,\height) -- (0,\height) -- (0,0);
  \fill[fill=background]
    (0,0) -- (30:#1) -- ++(0,\height) -- (0,\height) -- (0,0);

  % Draws the facades
  \facade{\stories}{#1}

  % Frames the facades
  \draw[draw=shadow] (0,0) -- (150:#1) -- ++(0,\height) -- (0,\height) -- (0,0);
  \draw[draw=light] (0,0) -- (30:#1) -- ++(0,\height) -- (0,\height) -- (0,0);

  % Draws the terrace
  \fill[fill=background, draw=light,shift={(90:\height)}]
    (0,0) -- (30:#1) -- (0,#1) --(150:#1)--(0,0);

  %
  \pgfmathrandominteger{\alea}{0}{3}
  \ifthenelse{\alea=0}{
  % Sometimes, adds more stores (= skyscraper)
    \begin{scope}[shift={(0,\height)},shift={(0,0.05)}]
      \pgfmathsetmacro\pside{#1-0.1}
      \pgfmathrandominteger{\stories}{2}{\storeymax}
      \block{\pside}{\stories}
    \end{scope}
  }{}

  \ifthenelse{\alea=1}{
  % Sometimes, draws a pyramid roof
  \pyramid{\height}{#1}
  }{}
}

% Draws a basic block
\newcommand\basicblock[3]{
  % Selects a random facade style
  \pgfmathrandomitem{\facade}{facade}
  \setvthickness{}
  \seththickness{}

  % Selects a random number of stores
  \pgfmathrandominteger{\stories}{\storeymin}{\storeymax}

  \begin{scope}[shift={(\xaxis:#1)},shift={(\yaxis:#2)}]
  \block{#3}{\stories}
  \end{scope}
}

% Draws a pyramid roof
\newcommand\pyramid[2]{
  % Computes the side of the pyramid
  \pgfmathsetmacro\pside{#2-0.1}

  % Selects the height of the pyramid at random
  \pgfmathparse{random()}
  \pgfmathsetmacro\top{0.5+\pgfmathresult/3}

  % Draws the pyramid
  \begin{scope}[fill=background, draw=light,shift={(90:#1)},shift={(90:0.05)}]
    \fill[draw=light] (0,0) -- (30:\pside) -- (0,\top) -- (150:\pside)--(0,0);
    \draw (0,0) -- (0,\top);
  \end{scope}
}

% Draws a random city of the specified dimensions
\newcommand\city[2]{
  \foreach \x in {1,...,#1}
    \foreach \y in {1,...,#2}
      {\basicblock{\x}{\y}{\defaultside}}
}

\begin{document}
% Draws a hundred blocks random city
\begin{tikzpicture}[show background rectangle,
  background rectangle/.style={fill=background}]
    \city{10}{10}
\end{tikzpicture}
\end{document}
